NEW 7,0” Multi-Interface TFT Development Board
Model Features:
>Operating Voltage: DC 8~48V or POE PD(Option) Vdc
>Communication Interface: LAN /CANFD /RS485 /RS232 /UART /I2C /USB
>MCU: STM32H747
>Flash Memory: 16 MB
>LCD Display Size: 7,0″
>Dot Matrix: 1024 x RGB x 600(TFT) dots
>Module Dimensions: 203.2(W) x 116.5 (H) x 25.8(D) mm
>Active Area: 154.21 x 85.92 mm
>Pixel Pitch: 0.1506 x 0.1432 mm
>Brightness: Min: 800; Typ: 850 cd/m2
>LCD Type: TFT, Normally Black, Transmissive
>LCD Panel: 169.9(W) x 103.4(H) x 7.3(D) mm
>Viewing Direction: 85/85/85/85
>Aspect Ratio: 16:9
>Touch Panel: Projected Capacitive Touch Panel (PCAP)
>Surface: Glare
>GPIO: 16 CH
>SD Card: Micro SD slot
>Operational Temperature Range: -20°C to +70°C
>Storage Temperature Range: -30°C to +80°C
